Heat Exchanger / Condenser Precision Steel Tube Astm A179 Low Carbon Steel

Name: Heat Exchanger Condenser Precision Steel Tube Astm A179 Low Carbon Steel
Brand: Torich
Price: 1 USD

Heat Exchanger / Condenser Precision Steel Tube Astm A179 Low Carbon Steel Manufactures

Brand Name : Torich

Model Number : SA178, A179, A192, A210, SA213

Certification : ISO9001:2008 ISO14001:2008

Place of Origin : Zhejiang, China (Mainland)

MOQ : 3 TON

Price : US $750 - 1,200 / Ton

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 20000 Ton/Tons per Year

Delivery Time : 20-40 WORK DAYS

Packaging Details : in bundles with seaworthy packing

Shape : Round

Grade : Low Carbon Steel Chinese Grade10#

Usage : For Boilers , Superheaters , Heat-Exchanger , Condensers

Surface : With Anti Rust Oil

OD : 3.2-76.2mm

WT : 1-15mm

Contact Now

Heat Exchanger / Condenser ASTM A179 Seamless Cold Drawn Low-Carbon Steel Tubes

ASTM A179 Seamless Cold Drawn Low Carbon Steel Heat Exchanger Tubes and Condenser Tubes
Seamless Cold-Drawn Low-Carbon Steel Heat-Exchanger Tubes and Condenser Tubes

Product Name::	Torich Cold Drawn Seamless Alloy Steel Tube With Carbon ASTM A179 SA178, A179, A192, A210, SA213, SA214	Material::	SA178, A179, A192, A210, SA213, SA214
Surface::	With Anti Rust Oil	Application::	Structure, High Temperature, Liquid Transportation Pipe And Tubes For High Pressure Boiler
Shape::	Round	OD::	3.2-76.2mm
WT::	0.5-200mm	Length::	4-12.5m
Tolerance::	According To The Following Tables Or Customers’ Request.	Spec::	General Length:4-12.5m

Applications:

For Boilers,
Superheaters,
Tubular Heat-Exchangers,
Condensers
Heat transfer apparatus

U bend Tubes according to Customer request

Material: Low Carbon Steel

Production: Seamless Cold Drawn
Size range: O.D.:3.2-76.2mm W.T.:1-15mm L: according to customer requirement.

Steel Grade and Chemical Compositions:

C	0.06-0.18
Mn	0.27-0.63
P	≤0.035
S	≤0.035

Mechanical Properties
Tensile Streghth: min ksi[Mpa] 47[325]
Yield Point: min ksi[Mpa] 26[180]
Elongation: ≥35%
Hardness: ≤72HRB

Heat Treatment:
Tubes are heat treated after the final cold draw pass at a temperature of 1200℉(650℃) or higher

Surface Finish:
Finish Tubes are free of scale.
We have normal heat treatment annealing with black surface.
Have bright annealing with grey and bright surface.

Mechanical Testing:
Flattening Test
Flaring Test
Flange Test
Hardness Test

Heat Exchanger / Condenser Precision Steel Tube Astm A179 Low Carbon Steel

Heat Exchanger / Condenser Precision Steel Tube Astm A179 Low Carbon Steel

Heat Exchanger / Condenser Precision Steel Tube Astm A179 Low Carbon Steel

PACKAGING DETAILS:

Packing in wooden box,hexagonal bundles or other seaworthy ways.
